The primary function of a rotator is to rotate or tip loads up to 360 degrees in both directions. This allows operators to reposition, invert, or dump materials without leaving the cab or moving the entire truck.
Emptying & Dumping: empties bins, containers, or hoppers in waste management, recycling, and agriculture.
Inverting Loads: Flips items like molds, drums, or pallets in manufacturing and food processing.
Material Handling: Positions bricks or blocks in construction, mixes materials like compost, and aligns pallets in warehouses.
Core Industries: waste management, agriculture, food processing, manufacturing, construction, and recycling
| Capacity@ Load Center |
Model | Mounting Class |
Fork Mounting Class |
Overall Width |
Max.Notch Spacing |
Weight | Effective Thickness |
Horizontal Center of Gravity |
| (kg@mm) | (mm) | (mm) | kg | (mm) | (mm) | |||
| 1700@500 | RT-20M-A01 | ISO 2A | ISO 2A | 860 | 780 | 195 | 137 | 61 |
| 2300@500 | RT-25M-A03 | ISO 2A | ISO 2A | 990 | 790 | 330 | 221 | 125 |
| 3500@500 | RT-35M-B02 | ISO 3A | ISO 3A | 1260 | 1060 | 385 | 226 | 120 |
| 5000@500 | RT-50M-B01 | ISO 3A | ISO 3A | 1250 | 1144 | 505 | 201 | 84 |
| 5400@600 | RT-50M-C01 | ISO 4A | ISO 4A | 1530 | 1300 | 550 | 238 | 100 |
| 6800@600 | RT-70M-C01 | ISO 4A | ISO 4A | 1530 | 1300 | 850 | 238 | 100 |
| 6800@600 | RT-70M-C02 | ISO 4A | ISO 4A | 1550 | 1310 | 980 | 202 | 110 |
