Capacity | Model | Class | Opening Range | Long Arm | Short Arm | Arm thickness | H × W | CGV | CGH | ET | Service Weight |
(mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (Kg) | |||
1300 | FRC-20M-A01 | 2 | 330-1150 | 685 | 515 | 45 | 635×190 | 330 | 216 | 138 | 345 |
1200 | FRC-20M-A02 | 2 | 410-1300 | 790 | 580 | 45 | 635×190 | 330 | 222 | 138 | 345 |
2000 | ARC-25M-A/B01 | 2/3 | 250-1300 | 824 | 570 | 45 | 840×235 | 345 | 295/330 | 210/250 | 730/748 |
2000 | FRC-25M-A/B01 | 2/3 | 630-1300 | 824 | 570 | 45 | 840×235 | 345 | 290/325 | 210/250 | 720/738 |
2000 | ARC-25M-A/B02 | 2/3 | 350-1600 | 956 | 774 | 90 | 840×235 | 345 | 310/320 | 210/250 | 838/848 |
2000 | FRC-25M-A/B02 | 2/3 | 630-1600 | 956 | 774 | 90 | 840×235 | 345 | 308/318 | 210/250 | 826/836 |
1700 | FRC-35M-B01 | 3 | 680-1830 | 1130 | 930 | 112 | 840×235 | 345 | 458 | 210/250 | 950 |
1700 | ARC-35M-B01 | 3 | 380-1830 | 1130 | 930 | 112 | 840×235 | 345 | 460 | 210/250 | 965 |
2700 | FRC-50M-B/C01 | 3/4 | 520-1300 | 850 | 590 | 85 | 960×235 | 445 | 270/290 | 210/250 | 820/840 |
2700 | ARC-50M-B/C01 | 3/4 | 250-1300 | 850 | 590 | 85 | 960×235 | 445 | 270/290 | 210/250 | 835/855 |
2700 | FRC-50M-B/C02 | 3/4 | 560-1520 | 970 | 690 | 70 | 960×235 | 445 | 305/322 | 210/250 | 880/900 |
2700 | ARC-50M-B/C02 | 3/4 | 255-1520 | 970 | 690 | 70 | 960×235 | 445 | 305/322 | 210/250 | 898/918 |
2300 | FRC-50M-B/C03 | 3/4 | 680-1830 | 1125 | 825 | 88 | 960×235 | 450 | 352/372 | 210/250 | 995/1016 |
2300 | ARC-50M-B/C03 | 3/4 | 380-1830 | 1125 | 825 | 88 | 960×235 | 450 | 352/372 | 210/250 | 1018/1040 |
