1. 2 pieces of truck auxiliary valves are necessary. 140bar≤Working Pressure≤180bar.

Note: if ordered with remote control valve, only 1piece of truck auxiliary valve requested!

2. Big Range from 1ton to 10ton capacity,800mm to 2400mm width,Class II to Class V.

3. If not requested, Positioners are shipped without the backrest holes.

4. The Positioner capacity is at 600mm load center.

5. Fitting Screw M14X1.5-74°(concave)(2A,3A), M18X1.5-74°(concave)(4A,5A);

Recommended Hydraulic Pipe internal diameter 8mm(2A,3A),10mm(4A,5A).
